8 Smart 3D
Operator’s Manual 8 - 9
3. Swipe on the current active MPR to view the image. The other two MPRs change
correspondingly.
The adjustment of Rendering Parameters
In image viewing status, you can render the image by adjusting the relevant parameters.
Tap [VR] or [MPR] to select the VR parameters or MPR parameters.
• When [VR] button is highlighted, adjust parameters of 3D image (VR).
• When [MPR] button is highlighted, adjust parameters of sectional image.
You can adjust:
Reset Curve
Do one of the following to reset the curve:
Item Description
Threshold Set the threshold for 3D image rendering. 3D image is rendered on the
signal above thresholds by eliminating noise via the Threshold
parameter. Lower threshold can eliminate lower range noises and echo,
which will contribute to a clearer and smoother image.
Available only in Surface rendering mode.
Opacity Adjust the transparency value for 3D image rendering. It implies the
transparency of the light. The higher the value is, the tougher the
surface becomes.
The lower the number is, the more transparent the gray scale
information will be.
Available only in Surface rendering mode.
Smooth Set the smoothness of 3D image.
NOTE:
Insufficient smoothness can result in a fuzzy image; however, too
much smoothness will lead to image distortion.
Brightness Set the brightness of image.
NOTE:
The adjustment is for 3D (VR) and MPR.
Contrast Set the contrast scale of the image.
As long as the contrast becomes larger, the bright spot and dark spot on
the image change as well.
NOTE:
The adjustment is for 3D (VR) and MPR.
Tint Enable/disable tint map. The color of image change according the tint
value.
VR Orientation Rotate the 3D image quickly.
iClear Enhances the B mode image profile for better boundary details.
Item Description
Ori To reset the volume rotation, shifting and zooming of 3D image to
original status.
