Mindray TEX20 Operator's Manual

4 Setup
Operator’s Manual 4 - 13
4.1.10 Scan Code Preset
Set the code parameters for barcode reader.
1-dimension barcode reader (1D)
User field name Select [Use user field name] to customize the user field name. After
that, the members and privileges cannot be edited.
Enter the user field name in the field box of the “User field name”
(the user field names are configured in the LDAP server. For details,
please refer to the LDAP server manual).
The user field name corresponding to privileges are as follows:
• iStation Access: 1
• Save Exam: 2
• Export Exam: 4
• Network Settings: 8
• Maintenance Menus: 16
• System Settings: 32
• Workflow Settings: 64
• Worklist Access: 128
NOTE:
The privilege items can be combined randomly. For example, if
user A is assigned with all the above 8 privileges, the user field
name for user A is 1+2+4+8+16+32+64+128=255.
Item Description
Item Description
Scan Item After scanning 1D bar code, the regular expression is matched in the priority
order: “Patient ID > Other ID > First name > Last name > Middle name >
Accession# > Operator > Diagnostician”. If the regular expression is
matched successfully, the data of 1D bar code will be displayed in this item
in Patient page automatically.
Example: The data of the bar code is 123 after scanning 1D bar code. The
regular expression is matched in the priority order: “Patient ID > Other ID >
First name > Last name > Middle name > Accession# > Operator >
Diagnostician”. If the regular expression of “Other ID” is matched
successfully, “123” will be displayed in “Other ID” item in Patient page
automatically.
Regular
Expression
Set the regular expression according to the bar code format.
Move Up/Down Move up or Move down a selected item.
Add/Delete Add or delete a selected item. (Only the default item can be added or
deleted.)
Load default Restore the parameter value to the default value.
