2 - 20 Operator’s Manual
2 System Overview
2.11.7 iVocal Plus
TIP:
• If the microphone is not to be used for the moment, you can put the microphone into the vacant
probe holder temporarily.
• When the iVocal Plus function is enabled, the system can perform operations both through
inputting vocal commands and through selecting icons on the touch screen.
• The ultrasound system can automatically recognize some vocal commands. For details about
the vocal commands, see “D List of Vocal Commands”.
• Currently, only wireless microphone devices can be inserted to the system for inputting vocal
commands.
Before enabling the iVocal Plus function, insert the iVocal microphone device or iVocal Plus
Microphone Array to the USB port of the ultrasound system through the USB extension wire. Tap
and select [iVocal Plus] to activate the function.
Inputting vocal command
Perform the following procedure:
1. Select the icon in the Audio Control menu to start the vocal command recognition.
No. Name Function
1. Edit Comments
button (on
Comment menu)
Select to enter comment preset page, you can add custom comments
and change comment layout.
Edit Markers
button (on Body
Markers menu)
Select to enter body mark preset page, you can change body mark
layout.
2.
Arrow button Select to add arrow a comment to the image.
3.
Keyboard button
Select to activate the soft keyboard to type the alphanumeric
characters.
4. Clear Comments
button (on
Comment menu)
Select to delete all the annotations.
Clear Markers
button (on Body
Markers menu)
Select to delete the added body mark.
5. Annotation text
library
System preset comments.
If there is more than one page of comment texts for the current exam
mode, you can slide to view more.
6. Body Markers tab Select to enter bodymark status.
7. Comment tab Select to enter text/arrow comment status.
