2 - 22 Operator’s Manual
2 System Overview
• Wakeup mode: Select to enable wakeup mode. If the wakeup mode is enabled, the iVocal Plus
will automatically shut down after each command is executed. If the wakeup function is not
enabled, the iVocal Plus will only shut down after the waiting time.
• Enable voice response: Select to enable this function. When the function is enabled, the iVocal
Plus will respond to your voice command.
• Automatically shut down waiting time (Sec): Tap to enter number of the waiting time.
2.11.8 Splitting Display
The system supports dual-split display format. However, only one window is active.
Dual split:
1. Select [Dual] to be “on” from B image menu to enter dual-split mode.
2. Select each window to switch the active window (marked with “m” icon.)
3. Select [B] or select [Dual] to be “Off” to exit to single window.
2.11.9 Image Magnification
Zooming an image changes the frame rate which tends to change thermal indices. The position of
the focal zones may also change which may cause the peak intensity to occur at a different location
in the acoustic filed.As a result, the MI may change.
Do one of the following to zoom in/out the image:
• Use two fingers to pinch on the image area to zoom in/out the image.
• Use [Zoom Value] in the image parameter control menu to change the magnification factor.
For the following mode, you need to Select [Image] > [B] to highlight B menu first.
– B+Color
–B+M
–B+PW/CW
– B+Color+PW/CW
– B+Power+PW/CW
The image magnification factor value will display in real time in the image parameter area.
Icon Function
Audition the vocal command
Delete the vocal command
Rename the vocal command
Add the failure time by 1
Clear the Success Rate test record of the selected vocal command
To Next Page
