Mindray TEX20 Operator's Manual

2 - 24 Operator’s Manual
2 System Overview
For B/B+Color/B+Power mode, bottom-left corner will indicate current frame and total frames.
For B/B+M/B+PW/B+CW mode, bottom-left corner will indicate time played and total time.
To Exit Cine Review
Select [Freeze] or [B] and the system will return to image scanning and exit cine review.
2.12.2 Manual Cine Review
After entering cine review in 2D mode, drag playback mark to review the cine images on the screen
one by one.
Drag the playback mark to the left to display the earlier stored images; drag the playback mark to
the right to display the recently stored images. Select Minus/Plus button to fine tune the playback
mark.
Or, swipe the image area to the right to display the earlier stored images; swipe the image area to
the left to display the recently stored images.
2.12.3 Auto Review
Reviewing all
Perform the following procedure:
1. In manual cine review status, Select to activate auto cine review.
2. Review speed: in auto cine review status, drag the mark to select different speeds: 1/10x, 1/5x,
1/4x, 1/3x, 1/2x, 1x, 2x, 3x.
3. In auto play status, Select to stop auto play.
1Start mark
2 Playback mark
3End mark
4 Auto Review Region
5 Minus button
6 Plus button
2
4
5
1
3
6
