3 - 8 Operator’s Manual
3 System Preparation
The display can be rotated as shown below.
3.6 Connecting/Disconnecting a Probe
• Use [Freeze] to freeze an image or turn off the power of the system before
connecting/disconnecting the probe. Otherwise, system or probe failure
may occur.
• When connecting or disconnecting a probe, place it in the proper position to
prevent the probe from falling off or becoming damaged.
• Only use probes provided by Mindray. Aftermarket probes may result in
damage or cause a fire.
3.6.1 Connecting a Probe
The probes, cables and connectors should be in proper operating order and
free from surface defects, cracks and peeling. Otherwise, this may lead to
electrical shock.
Before inserting the connector into the probe port, inspect the connector pin. If the pin is bent, do
not use the probe until it has been inspected/repaired/replaced.
90°
To Next Page
