2 System Overview

Operator’s Manual 2 - 23

2.11.10iZoom (Full Screen View)

This feature magnifies the image area in full screen for a better observation.

2.11.11Freeze/Unfreeze the Image

Select [Freeze] to freeze a scanning image. In freeze mode, the probe stops transmitting acoustic

power, and all images and parameters are frozen.

TIP:

After freezing an image, the system may enter cine review, measure, comment adding, body mark

mode or current mode, depending on what has been preset.

Select [UnFreeze] in freeze mode to unfreeze the image, and the system continues image scanning.

2.11.12Imaging Mode Switching When Frozen

Imaging mode switching in freeze mode follows these principles:

• In splitting display B mode, Select each image window to switch between the windows.

• In freeze mode, the system supports imaging mode switching between the sub-modes (only for

the activated window). For example, if the frozen image is in B+Color+PW mode, the system

supports imaging mode switching between B+Color+PW, B+Color, B+PW and B by selecting

[Color] or [PW].

2.12 Cine Review

After selecting [Freeze], the system allows you to review and edit the images prior to the image

being frozen. This function is called cine review. You can perform zoom, measurements, add

comments and body marks on the images being reviewed.

The system supports manual review as well as automatic review.

In addition, the system supports the images reviewed along with physiological waveforms, if the

detection of physiological waveforms is performed.

CAUTION

• Cine Review images can be inadvertently combined in-between separate

patient scans. The Cine Review memory must be cleared at the end of the

current patient exam and before starting the next new patient exam by

selecting [End Exam] on the touch screen.

• Cine files stored in the system's hard drive should contain patient

information, to avoid the selection of an incorrect image file and potential

misdiagnosis.

2.12.1 Entering/Exiting Cine Review

To Enter Cine Review

• Enter Tap > [Setup] > [System]> [Image] > “Freeze Config” screen to set “Status after

Freeze” to “Cine.” The system enters manual cine review status once [Freeze] is selected.

• Open cine files in Review screen. The system enters automatic cine review status.

Under cine review status, cine review control bar will be displayed on the cine menu.
