12 DICOM/HL7
Operator’s Manual 12 - 3
4. Select the desired patient record in the displayed patient list.
a. Select the desired patient and click [Start Exam]. The patient information is imported into
the system and then an exam is started.
b. Select [Transfer] and the patient information is imported into the [Patient Info] screen.
After editing the patient information in the Patient Info screen, select [OK] to start a new
exam.
c. Select [Show Detail] to see details of patient data.
5. Select the desired patient and tap [Done]. The patient information is imported into the system
and then an exam is started.
12.4 MPPS
MPPS is used to send exam state information to the configured server. This facilitates the other
systems in obtaining the exam progress in time.
After you preset the Worklist server and MPPS server, if the system obtains the patient information
from Worklist server to begin the exam, it will send exam status information to MPPS server of
when the exam is undergoing or ended. If the sending fails, the system resends automatically.
12.5 Storage Commitment
Storage commitment is used to confirm whether the images or structured reports are successfully
stored on the DICOM storage server.
Before using storage commitment, set the associated storage service.
If images are successfully sent to the storage server, in the iStation screen, “PACS received, OK” is
displayed in the list below “Storage Commitment”.
Multi-frame storage is not allowed if “Allow Multiframe” is not selected (For details, see DICOM
Service Preset in the Setup chapter). For example, even if there is a multi-frame file in the exam to
be sent, only single-frame image storage will be performed. After the storage is complete, there is
no “√” marked in the list of the iStation screen.
12.5.1 Storage commitment after sending images on the
iStation screen
Select the image, the cine or the data, and send it, see “12.1 DICOM Storage”.
The system will send all the images stored in the exam record to the storage server. Meanwhile, it
will send storage commitment to the storage commitment server.
12.5.2 To send storage commitment automatically after an
exam ends
• Preset Sending/printing after End Exam, for details see “4.1.2 General”.
• Set the default storage server, and click “Storage Commitment” to connect to the storage
server, see “4.7.2 DICOM Service Preset”.
