13 Probes and Biopsy

Operator’s Manual 13 - 3

LAP13-4Cs Convex

L14-5sp Linear

L11-3VNs Linear

L12-3RCs Linear

L12-3VNs Linear

C9-3Ts Convex

i3P Phased

i3PA Phased

L14-3Ws Linear

Probe model Probe Type Probe Figure
