Mindray TEX20

13 - 58 Operator’s Manual
13 Probes and Biopsy
In Plane Needle Guidance GUI
Out of Plane Needle Guidance GUI
1 Needle position in the ultrasound plane
2 Needle tip position in the ultrasound plane
3 Needle guidance trajectory
4 Scale of guideline (5 mm/scale)
3
4
2
1
1 Needle projection position in the ultrasound plane
2 Position at which the needle cross the ultrasound plane
3 Projection position of the needle guidance trajectory in the ultrasound plane
4 Scale of guideline (5mm/scale)
3
4
2
1
