2 - 28 Operator’s Manual
2 System Overview
The name, pattern and meaning of each symbol and warning label are described as follows:
Symbol Description
Type-BF applied part
The ultrasound probes connected to this system
are type-BF applied parts.
The ECG leads within this system is type-BF
applied part.
Caution!
Standby
Transducer sockets
AC (Alternating current)
Foot switch
USB port
Extending port
High definition multimedia interface
Unlock position
Lock position
Network port
USB interface (Type C)
Probe direction indicator
Power input
Maximum load for front storage bin.
Maximum load for printer bracket
