4 - 24 Operator’s Manual
4 Setup
The following physiological indicators can be added to the formula.
4. Verify the formula, select the unit of the result, then select [Complete]. The user-defined
calculation item is listed in the “User-defined” category of “Available Items.”
In the meantime, the user-defined item will be added automatically to the “Selected Items” in
the Report template. If the item is completed in an exam, the results will be displayed in the
report.
User-defined Study Items
Perform the following procedure:
1. In Measure page, select [Add Study].
2. Enter the study name in the dialog box that appears.
3. Select [OK] and the item will be added to the “Selected Items.”
4. Select a measurement/calculation item from the “Available Items” and select [>] to add the
item to the user-defined study.
log log(a) 1 Logarithm with 10 as the base
avg avg(a,...) ≥1 Average value
abs abs(a) 1 Absolute value
PI PI / Constant π, 3.1415926
NOTE:
The letter “a” and “b” in the “Method” Column are parameters.
Name Definition Unit
Age Age day
BSA Body surface area m
2
PSA Prostate specific antigen ng/ml
PPSA Coefficient PPSA Coefficient ng/ml
2
RAP Right atrial pressure mmHg
GA Gestational age day
Height Height cm
Weight Weight kg
Heart Rate Heart rate bpm
High BP(CAR) High blood pressure (Cardiac) mmHg
Low BP(CAR) Low blood pressure (Cardiac) mmHg
High BP(VAS Left) High blood pressure (Left Vessel) mmHg
Low BP(VAS Left) Low blood pressure (Left Vessel) mmHg
High BP(VAS Right? High blood pressure (Right Vessel) mmHg
Low BP(VAS Right) Low blood pressure (Right Vessel) mmHg
Function Method Parameter Number Function Description
