2-4 Mx-Series Manual
Mx200/P/TP: Configured in a different structure as a VME base
control system is used. For further information on components,
contact the Mirae CS personnel.
Mx100,200 Interior Parts
REAR
① Head Assembly
Mx100 : 4 Module, Mx100P : 2 Precision
Mx200 : 6 Module, Mx200P : 4M+1P(4 Module +1 Precision)
Mx200TP : 3 Precision
② Conveyer Assembly: 410(W)x460(D), Option: Automatic width adjustment
③ M-ANC Assembly (Automatic Nozzle Changer for module head) Mx100/P: Rear
ANC is optional. ④ FOV24 Standard Camera Assembly Mx100/P: REAR Camera is
optional.
⑤ Feeder Base Assembly
Mx100/P: Rear Feeder Base is optional.
