Chapter 2 Machine Overview
2-5
Mx100P,200P/TP Interior Parts
① Head Assembly
Mx100P : 2 Precision
Mx200P : 4M+1P(4 Module +1 Precision), Mx200TP : 3 P(3
Precision)
② Conveyer Assembly: 410(W)x460(D), Option: Automatic
width adjustment
③ Module ANC Assembly
④ P-ANC Assembly
⑤ FOV24 ST Camera Assembly (or SIDE or ST/SIDE)
⑥ FOV24 SIDE Camera Assembly: Option
⑦ FOV36 DQFP Camera Assembly
⑧ Feeder Base Assembly
Mx100/P : Rear Feeder Base is optional.
