2-6 Mx-Series Manual
⑨ TFU Assembly (Tray Feeder): TF-5
Mx200(Option: M S-1
Attached) Interior Parts
※ MS-1 (Multi-tray Supply Unit): Supplies 60 Jedec trays to the
left and right. MS1① -L MS② 1-R
Applied Models: Mx-100/P,Mx200/P/TP Front
Mx400/P Exterior Parts
FRONT
REAR
②
RIGHT
LEFT
IN
OUT
①
