Chapter 5 Solutions for Errors 5-
19
11021
Up/Down/Left/Right
lead angle offset error
Contact the C/S engineer.
11096
Calibration point limit
exceeded
Too many circles are detected in
recognition of the jig for camera
calibration. Check the circle of jig and
adjust the background illumination of
the calibration jig.
11097
Image calibration point
error
Check the circle of jig and adjust the
background illumination of the
calibration jig.
Error Code
Message
Description
Actions
References
11098
Calibration error
(Singular error)
Check the circle of jig and adjust the
background illumination of the
calibration jig.
11099
Unidentified
calibration error
Check the circle of jig and adjust the
background illumination of the
calibration jig.
11100
Vision
communication
error (when getting
semaphore)
Enter the Vision Reset command on the
Mrterminal and, after 30 sec, enter the
ksh command to resume the task. If an
error occurs, make sure to contact the
C/S engineer and to capture the screen.
11101
Vision
communication
error (when returning
semaphore)
Enter the Vision Reset command on the
Mrterminal and, after 30 sec, enter the
ksh command to resume the task. If an
error occurs, make sure to contact the
C/S engineer and to capture the screen.
11102
Calibration error
(rotation)
Enter the ksh command on the
Mrterminal. If the problem is not
resolved, enter the Vision Reset
command and, after 30 sec, enter the
ksh command to resume the task.
11103
Vision system down
(no response)
Enter the Vision Reset command on the
Mrterminal and, after 30 sec, enter the
ksh command to resume the task. If an
error occurs, make sure to contact the
C/S engineer and to capture the screen.
5-45
11104
Communication error
with the vision
system (result
packet)
Enter the Vision Reset command on the
Mrterminal and, after 30 sec, enter the
ksh command to resume the task. If an
error occurs, make sure to contact the
C/S engineer and to capture the screen.
11105
Mark area error
(VErrorCode=407)
Using the mark menu of the program
editor, extract an exact size parameter
of the mark around the mark position
and then retry. If an error occurs, make
sure to contact the C/S engineer and to
capture the screen.
11201
Database
information error
If an error occurs, make sure to contact
the C/S engineer and to capture the
screen.
