Mirae Mx400 - Page 373

Chapter 5 Solutions for Errors 5-
21
11231
X-Length is too small.
The component size (X-length)
defined in the component DB is
different from the chip size inspected
from vision. Check that the size is
exactly entered in the component
DB and that the component is not
picked up vertically. Check whether
the tolerance for chip size inspection
is too small (This does not concern
the centering option that does not
apply tolerance). If components are
frequently picked up vertically, check
and adjust component feeding from
the feeder, picking position, picking
height, etc.
Error Code
Message
Description
Actions
References
11232
X-Length is too
large.
The component size (X-length) defined
in the component DB is different from
the chip size inspected from vision.
Check that the size is exactly
entered in the component DB and
that the component is not picked up
vertically. Check whether the
tolerance for chip size inspection is
too small (This does not concern the
centering option that does not apply
tolerance). If components are
frequently picked up vertically, check
and adjust components feeding from
the feeder, picking position, picking
height, etc.
11235
Y-Length is too
large.
The component size (Y-length) defined
in the component DB is different from
the chip size inspected from vision.
Check that the size is exactly
entered in the component DB and
that the component is not picked up
vertically. Check whether the
tolerance for chip size inspection is
too small (This does not concern the
centering option that does not apply
tolerance.). If components are
frequently picked up vertically, check
and adjust component feeding from
the feeder, picking position, picking
height, etc.
