Mitel 3000 Installation And Maintenance Manual

Mitel 3000
Installation & Maintenance Manual
126
Technical specification
Type of system Hybrid/PBX
CO lines Max 20 CO lines
Terminals
Max 40 Standard DTMF Telephones
Max 40 ECX 8-key Feature Phones
Max 40 16-key Feature Phones
Max 8 DSS – Additional 32 programmable keys
Max 12 IP phones (Mitel 3000 compatible only)-Broadband module
required.
Extension capacity 40
IP Extensions (Mitel 3000 compatible only) 12 (Broadband module required)
Feature Phone capacity 40
Standard 2-wire apparatus capacity 40
Extension loop resistance
100 ohms (1600 feet) 4-wire Feature Phones
400 ohms (6500 feet ) standard DTMF telephones
System REN > 40
Extension REN 2 (see above for system max.)
Extension cabling
Standard 4 wire
Twisted pair 0.5 mm
2
cu
Main Equipment (CCU) 008
Height 15.4 inches (390 mm)
Width 11.6 inches (295 mm)
Depth 6.3 inches (160 mm)
Weight 13.5 pounds (6.1 kg)
Maximum capacity system 8+32 CCU
Height 15.4 inches (390 mm)
Width 23.4 inches (595 mm)
Depth 6.3 inches (160 mm)
Weight 13.5 pounds (6.1 kg)
Battery 12 V/7.2 AH
Main AC power supply voltage 230  10% V 50 Hz
Maximum power consumption 350 watts
Standard 2-wire telephone signaling DTMF
Standard 2-wire telephone recall signal Timed break
Serial Port 8 bit, no parity, 1 stop bit speed programmable 115k2
Voice Mail Capacities
2 Port 5 hours messaging capacity supporting 40 mailboxes, 10 Phantom
Voice Boxes, 20 Group Boxes
4 Port 10 hours messaging capacity supporting 40 mailboxes, 10
Phantom Voice Boxes, 20 Group Boxes
8 Port 20 hours messaging capacity supporting 40 mailboxes, 10
Phantom Voice Boxes, 20 Group Boxes
Maximum message length is default at 3 minutes but is programmable up
to 5 minutes
Music on hold Internal or External source
Tone on hold 200 ms on 200 ms off, 200 ms on 3.4 s off
External Music on hold
Stereo jack connector
Input impedance 10k ohm
Nominal 775 mV RMS
External Paging Port Output Level 25 - 32mA Impedance 600 ohm
System speed dial numbers Max. 500
Extension current and voltage feed
Voice 40 volts 25 mA constant current
Data 40 volts 10 mA constant current
Dial tone duration 10 s
Programming Feature Phone (default extension 20) or PC Wizard through serial port
Remote access On ISDN or CO lines. (Built-in V32bis modem)
Ringing voltage/frequency  40 V 50 Hz (trapezoid)
Ringing cadences
Incoming call 400 ms on 200 ms off,
400 ms on 2.0 s off
Internal call 1 s on 2 s off
Door Phone call 400 ms on 2.6 sec off
