Mitel 3000 - ADSL Test Results and DSL Status; ADSL Test Results Display; DSL Status Information

Mitel 3000
Installation & Maintenance Manual
82
7. Select the speed you require - 4800, 9600,19,200, 38,400 or 115,200 bps.
NOTE: To connect a printer or PC for call logging, use the call logging cable provided and connect one end to
the V24 interface on the Central Control Unit (CCU) and the other end to the serial device, (e.g. a PC or a
printer).
Sales - Service numbers
You can programme the Sales and Service numbers that are accessed under the Directory key on the Feature
Phones.
1. Enter the System Programming password and select “System”.
2. Press the Scroll Down key () until “Sales - Service Numbers” is displayed.
3. Select “System Service” to program the service number.
4. Select “System Sales” to program the sales number.
5. Enter the maximum number of messages to be stored per Mailbox.
NOTE: Do not enter the line access code when programming these numbers.
Voice Mailbox Capacity
You change the message capacity of Mailboxes from the default of 20 messages per Mailbox to a higher or lower
amount depending on demand.
1. Enter the System Programming password and select “System”.
2. Press the Scroll Down key () until “Mailbox Capacity” is displayed.
3. Select “Mailbox Capacity”.
4. Enter the maximum number of messages to be stored per Mailbox.
Press the speakerphone key to finish programming.
Voice Mailbox Capacity % Used
You can check the capacity that is used overall in the Voice Mail
1. Enter the System Programming password and select “System”
2. Press the Scroll Down key until “VM Capacity % Used” is displayed.
3. Select “VM Capacity % Used”.
The % of the capacity used overall is shown on the top line of the display.
The top line of the display indicates the percentage that is used.
NOTE: To examine the capacity used by individual extensions see page
87.
Account Codes
A programming option can be set which allows codes of four digits to be associated with external calls, both
incoming and outgoing, and these codes are presented on the Call Logging output. Two options are available.
The first is that the entry of account codes is optional and the user can choose to enter the code or not. The
second option is forced and in this case the user must enter the code before they can make an external call.
To Set up the Account Code Operation
1. From the programming extension, press the PROGRAM key.
2. Select “System Programming”.
3. Enter the System Programming Password and select “System”.
4. Press the Scroll Down key () until “Account Codes” is displayed.
5. Select “Account Codes”.
6. Select “Account Codes On”.
The option “Forced Extensions” is presented. This is selected if you wish to have some extensions programmed
so that they must enter an account code before dialing a number.
7. Select “Forced Extensions”.
8. Select the extensions.
