Mitel 3000
Installation & Maintenance Manual
9
Installing the main equipment
Equipment location
The equipment is intended for installation in a residential or office-type environment. It needs to be mounted at a
convenient working height on a dry, flat wall. The normal height is 5 feet from the floor to the bottom of the case.
Do not place the CCU where it will be subjected to excessive levels of heat, dust or high
humidity. Locating the equipment near sources of electromagnetic radiation, such as
heavy electrical switchgear, lift machinery or electric arc welders, should be avoided.
Allow at least six inches of free space all around the CCU for ventilation.
The CCU needs to be located within six feet of an isolated, dedicated power supply outlet. The CCU must not
share the same main supply socket with any other electrical appliance.
Mounting the CCU
When a suitable location has been found, mark the screw locations on the mounting surface, using the mounting
bracket provided.
If the CCU is being mounted on masonry or plasterboard, suitable wall plugs must be used. Drill and plug four
holes in the wall at the marked locations. The holes should be deep enough to accept a one-inch screw.
Wall mount bracket
