Mitel 3000
Installation & Maintenance Manual
2
Customer Owned Coin/Credit Card Phones
To comply with state tariffs, the telephone company must be given notification prior to connection. In some
states, the state public utility commission, public service commission or corporation commission must give prior
approval of connection.
Data Equipment
The table below shows which jacks are associated with which modes of operation:
Mode of Operation
USOC Jack
Permissive RJ11C
Programmable RJ41S and RJ45S
Systems
Facility Interface Codes (FIC), Service Order Codes (SOC), USOC Jack Codes and Ringer Equivalence
Numbers (REN) are shown in the table below for each port where applicable:
Port FIC SOC USOC Jack REN
PSTN 9.0Y 02LS2 RJ11 0.9B
ISDN _PRI RJ45
ADSL RJ11
Adjuncts – KX and PX Devices
When this adjunct is used with a leased system, permission of the owner should be requested for connection of
the adjunct.
KX-type telephones with message waiting lights and/or line status indicators can only be connected to host
equipment and never directly to the network.
KX devices can only be installed with the permission of the owner of the host equipment as “surgery” is often
required on the host system.
OEM Devices
The mounting of the certified unit in the final assembly must be made so that the certified unit is isolated from
exposure to any hazardous voltages within the assembly. Adequate separation and restraint of cables and cords
must be provided.
The circuitry from the certified unit to the telephone line must be provided in wiring that carries no other
circuitry unless specifically allowed by the rules (such as PC and PR leads). PC board traces carrying tip and
ring leads shall have sufficient spacing to avoid surge breakdown.
If the certified device is enclosed in an assembly, and is not readily accessible, the certification label must be
placed on the exterior of the cabinet for each type of certified device contained therein.
The final assembler must provide all applicable material (contained in this section) with the final equipment.
A modular plug or jack must be provided which complies with Part 68, Subpart F requirements for dimensions,
tolerances and metallic plating.
