Installation
Note:
In the following cases Not Configured is displayed along with the node number, the slot number
and the port number. In this state the system phone is not ready for operation:
• A terminal has been created at the connected port, but the address selection switch is
incorrectly set.
• No terminal has yet been created at the connected port.
User allocation
In the configuration each terminal is assigned to a user or a free seating pool. If a terminal has been
created at the connected port and the address selection switch is correctly selected but no user or free
seating pool is allocated to the terminal, the system phone display reads No Number and indicates the
terminal ID. In this state the system phone is not ready for operation.
Terminal type
The terminal type is specified along with the configuration of the system. Lines are also assigned to the line
keys there.
Note:
If the terminal type configured is incorrect, the system phone display shows the warning Wrong phone
type. In this situation, although the system phone can be used for basic telephone operations, none
of the added features will be available. The terminal type must be entered via WebAdmin or on the
terminal via login to the system configuration.
Carrying out a logon on the system phone: Long keypress (long click) on a function key. Set new
phone type appears next. Confirm with Foxkey Yes.
4.8.5.1 Digital system phones
General information
Accesses
Release 7.1
163 System Manual for Mitel SMB Controller
