Expansion Stages and System Capacity
3.4.3 Terminal and network interfaces
Table 24: Terminal and network interfaces
Max. number... SMBC AIN with SMBC as Master
Ethernet interfaces 4 per node
Network interfaces, total (FXO,
BRI-T, PRI, BRI-S ext.)
16 96
Terminal interfaces, total (DSI,
FXS, BRI-S)
38 200
DSI terminal interfaces
32
26
200
Analogue terminal interfaces FXS 22
1
200
BRI-S terminal interfaces 12
1
200
Analogue network interfaces FXO 16 64
Basic rate interfaces, total (BRI-T,
PRI, BRI-Sext.)
16 96
Primary rate interfaces PRI 4 32
SIP access 10 10
SIP access channels 240 240
3.4.4 Software assurance
Software Assurance (SWA) is Mitel’s comprehensive support offer which gives access to new software
releases, support services and SRM remote access to the communication server.
26
In maximum expansion network access is possible only via IP
Release 7.1
System Manual for Mitel SMB Controller 68
