Installation
CAUTION:
Components, interface cards or system modules can be damaged by electrical voltage.
Always shut down, then disconnect the communication server from the power supply and then wait 3
minutes before removing the housing cover.
CAUTION:
Components can be damaged by electrostatic discharge when touched. Always touch the earthed
metal case of the communication server before carrying out work inside the housing. This also applies
to interface cards and system modules that are no longer packed inside the ESD protective wrapping.
4.2.5 Wall mounting
There are two possibilities for wall mounting. In the first variant the front panel faces right (see Minimum
distances for wall mounting (front panel facing to the right)); in the second, it faces downwards (see
Minimum distances for wall mounting (front panel facing downwards)). The wall-mounting option chosen
will depend on the way the cables are routed. The LED display remains visible whatever the mounting
position, even when the cable cover is fitted.
CAUTION:
A wall-mounting option in which the front panel faces upwards or to the right is not permitted.
Inadequate heat dissipation can damage the communication server.
4.2.5.1 Minimum distances
To ensure adequate heat dissipation, minimum distances need to be maintained with other objects such as
cable ducts, cabinets or mobile objects. Maintaining minimum distances also allows the installation of the
cable cover and the possibility of suspending the communication server into and out of the wall-mounted
screws.
The two diagrams below illustrate the two wall-mounting possibilities.
Release 7.1
87 System Manual for Mitel SMB Controller
