Annex
• Maximum of 2 simultaneous call connections
Analogue terminal interface FXS
• Configurable multifunctional interface for connecting analogue terminals and equipment.
• The following applies for the FXS mode Phone / Fax, two-wire door and general bell:
• Voice path with A/D and D/A conversion (standard PCM, A-law)
• Transmission as per ES 201 168 (level country-specific)
• Constant-current loop supply approx. 25 mA (with loop resistance £ 1000 W)
• Receive pulse or DTMF dialling
• CLIP display on 2 analogue terminals interfaces simultaneously.
• Ringing supply 40…43 V 50 Hz at load 4kW; no DC voltage overlay (country-specific versions also
with 25 Hz)
• No control key detection
• No charge signalling pulses
• For more technical details and cable requirements see Multifunctional FXS interfaces.
7.4.3 Communication server
Table 105: Dimensions and weights
Mitel SMBC for wall mounting Mitel SMBC in rack mounting
Height 65 mm 65 mm
Width 360 mm 483 mm
Depth 294mm 294mm
Weight (excl. mains cord,
interfaces cards, modules and
packaging)
2.4 kg 2.5 kg
Table 106: Electrical isolation of interfaces
Interface Mitel SMBC
Analogue network interfaces
TIC-4AB
0.2 kV Operating isolation
Release 7.1
277 System Manual for Mitel SMB Controller
