Operation and Maintenance
Table 90: Carrying out a first start and reset sales channel
No. PWR F0 F1 F2 F3 F4 F5 F6 SYS Duration Meaning
[21] ~11s Power is on,
begin of restart
[22] ~2s Do not touch
pilot key
[23] ~2s Press pilot key
to carry out a
first start and
reset sales
channel
[24] ~2s Confirmation
[25] ~50 Loading SMB
Controller
system software
[26] Normal mode,
SMB Controller
is up and
running
6.5 Operations supervision
6.5.1 Event message concept
The system generates an event message every time an event or error occurs. The event tables are used
to specify how often an event message of a particular type may be generated by the system over a given
period before the event message is sent to the allocated signal destinations.
There are 7 event tables that can be allocated to 8 signal destinations:
Figure 73: Distribution principle for an event message
Release 7.1
System Manual for Mitel SMB Controller 222
