Installation
CAUTION:
Be sure to observe the Safety regulations.
6. Remove the housing cover.
7. Connect the earthing (see Connecting the earthing wire).
8. Suspend the housing of the communication server onto the screws.
9. To secure the communication server screw in the long lower dowel screw (position C).
10. Fit the housing cover.
11. Secure the snap-on tag to the front panel or to a suitable position on the housing cover. The holes in
the housing cover are spaced in such a way that the snap-on tag can be secured both lengthways and
crossways.
12. Reconnect the communication server to the power supply.
4.2.6 Rack-mounting
The rack-mounting set allows the communication server to be installed horizontally into a 19” rack. Be sure
to observe the following:
• The communication server takes up the space of 1.5 height units inside the 19” rack. (1 Unit
corresponds to 44.45 mm).
• The holes in the mounting plates allow two communication servers to be placed directly above each
other with a space requirement of three units. Different holes in the mounting plates are used for this
purpose (see below figure).
• The space on the left and right between the communication server and the panels of the 19” rack is for
heat dissipation and must remain clear.
• With interface cards with more than 8 ports it is advisable to route the cabling via an fan-out-panel
(FOP) (1 height unit).
Release 7.1
91 System Manual for Mitel SMB Controller
