If an SB-8 / SB-8ANT is operated on two DSI interfaces, it is recommended always to use two
neighbouring ports.
Mitel Advanced Intelligent Network:
As the DECT systems of the individual nodes in an AIN do not run synchronously, the two DSI interfaces of
an SB-8 / SB-8ANT must always be connected to the same node.
Table 74: Operating state display on Mitel DECT radio units
LED flashing (two LEDs on the SB-8) Information
green Operating state
red / green Startup procedure running
orange Transmission of DECT sequences
red Fault
not flashing and not lit LED switched off or radio unit defective or not in operation
For further display variants, see Operating state of the Mitel DECT radio units.
4.8.7 Analogue phones Mitel 6710 Analogue, Mitel 6730
Analogue
The phones can be used as desktop model or as wall model.
Connecting the phone
1. Stick the connector on the longer, straight end of the handset cord on the underside of the phone into
the socket with the handset symbol until it snaps into place. Feed the cable through the strain relief and
connect the other end to the handset.
2. Feed the small connector of the phone connection cable on the rear side of the phone into the socket
until it snaps into place. Stick the connector on the other end into the phone cord.
Preparing the phone for message waiting indication (MWI)
Release 7.1
System Manual for Mitel SMB Controller 170
