Annex
Card/module Design
ETAB4 B
SM-DSPX1 D
SM-DSPX2 D
WA-TS0 F2
WA-TS1 F2
WA-2W
a
F1
WA-1PRI F1
Figure 77: Dimensions of interface cards (design A, B, C)
Figure 78: Dimensions of system module (design D)
Release 7.1
279 System Manual for Mitel SMB Controller
