13E
13E-35
E-44: EGR 2 (warning lamp flashes: 68) P1272
E-44: EGR 2 (warning lamp flashes: 68) P1273
E-45: EGR 3 (warning lamp flashes: 69) P1277
E-45: EGR 3 (warning lamp flashes: 69) P1278
E-48: Relay for Glow Relay (warning lamp flashes: 26) P0380
Generation condition
Exhaust gas recirculation solenoid valve (M/V-2) is shorted-circuited to ground,
or open circuited.
Recoverability System recovers if signal becomes normal with starter switch in ON position.
Control effected by electronic control unit Exhaust gas recirculation control is stopped.
Inspection
Service data 1F: EGR Position
Actuator test A2: EGR 2
Electrical equipment #530: Exhaust gas recirculation solenoid valve
Generation condition
Exhaust gas recirculation solenoid valve (M/V-2) is shorted to power supply cir-
cuit.
Recoverability System recovers if signal becomes normal with starter switch in ON position.
Control effected by electronic control unit Exhaust gas recirculation control is stopped.
Inspection
Service data 1F: EGR Position
Actuator test A2: EGR 2
Electrical equipment #530: Exhaust gas recirculation solenoid valve
Generation condition
Exhaust gas recirculation solenoid valve (M/V-3) is shorted-circuited to ground,
or open circuited.
Recoverability System recovers if signal becomes normal with starter switch in ON position.
Control effected by electronic control unit Exhaust gas recirculation control is stopped.
Inspection
Service data 1F: EGR Position
Actuator test A3: EGR 3
Electrical equipment #530: Exhaust gas recirculation solenoid valve
Generation condition
Exhaust gas recirculation solenoid valve (M/V-3) is shorted to power supply cir-
cuit.
Recoverability System recovers if signal becomes normal with starter switch in ON position.
Control effected by electronic control unit Exhaust gas recirculation control is stopped.
Inspection
Service data 1F: EGR Position
Actuator test A3: EGR 3
Electrical equipment #530: Exhaust gas recirculation solenoid valve
Generation condition Glow drive relay is short-circuited or open circuited or overload.
Recoverability System recovers if signal becomes normal with starter switch ON position.
Control effected by electronic control unit • Suspend glow control
Inspection
Service data 8D: Glow relay
Actuator test AF: Relay for glow relay
Electronic control unit connector : Glow drive relay
Electrical equipment #201: Glow drive relay
13
