13-22 Useful advice for emergencies
6. Remove the screws of the garnish , then
remove the garnish toward the outside of the
vehicle.
NOTE:
Do not remove the end rubber piece from the
garnish.
7. Remove the headlamp’s bolts .
8. Raise the headlamp slightly to remove the tabs
from the holes , then pull it out toward you.
Z21431
Z22067
Z21750
Z22088
