13-23
9. Remove the connectors from the headlamp
thus pulled out.
CAUTION
• Do not turn the beam adjusting gear . Turn-
ing the beam adjusting gear would change
the beam setting, thus creating a nuisance
for drivers of other vehicles. If you acciden-
tally turn the beam adjusting gear, have an
authorized dealer perform necessary inspec-
tion.
• When setting down the removed headlamp,
place it on a soft cloth to avoid scratching
the lens.
• Headlamp installation
1. Install the connectors on the headlamp.
2. Insert the tabs on the headlamp into the
holes , and fit the headlamp in place.
3. Fit the headlamp’s bolts .
Z21752
Z21753
Z22089
Z21750
FE_FG.book Page 23 Monday, December 19, 2011 4:22 PM
