1. Overview
No. 99MBA091A
1-9
②Rear view of the counter
ｄ）Serial output connector（1）
Connects to data processing devices such as the vision unit or QM-Data200
ｅ）Serial output connector（2）
Connects to Vision unit
ｆ）External illumination connector
This connector is used to connect an external lighting source from the optional
accessories (LED ring illuminator/twin fiber illuminator/ring fiber illuminator).
ｇ）External load connector
Connects to
external load switch
ｄ) Serial output
connector（1）
ｆ
)External illuminator
connector
ｅ) Serial output
connector（2）
ｇ) External load
connector
