X axis/Z2 axis selection key
Each time this key is pressed, the LEDs change in the following order: all lit → X
LED lit → Z LED lit → all off.
The axis for which the corresponding LED is lit can be moved by manipulating the
joystick.
X axis/Y axis selection LED
While this LED is lit, pushing or pulling the joystick lever side to side and back and
forth moves the X axis and Y axis, respectively.
This indication is valid only when a model with the Y-axis table is used or when the
optional Y-axis table is connected.
θ1 axis/θ2 axis selection LED
While this LED is lit, pushing or pulling the joystick lever side to side and back and
forth moves the θ1 axis and θ2 axis, respectively.
This indication is valid only when the optional θ1-axis table or θ2-axis unit is
connected.
ALT selection LED
While this LED is lit, the optional 2D auto-leveling table or 3D auto-leveling table
can be operated via the joystick.
This indication is valid only when the 2D auto-leveling table or 3D auto-leveling
table is connected.
3. Measurement related keys
These keys are used to measurement.
Start condition selection key
It is a key that selects the condition of the measurement start.
Each time this key is pressed, the LEDs change.
Start key is pressed while LED is lit, X-axis drive unit descends and start
measurement from the measurement start stylus position.
Start key is pressed while LED is lit, X-axis drive unit does not descends
and start measurement from the current detector position.
No. 99MBB187A
1-16
