Installation and Set Up
22 5016072 A
3. Align the mounting holes of the SpectraMax L baseplate with the
two mounting holes in the back of the StakMax “L” bracket. See
Figure 2-8.
Figure 2-8 Aligning the SpectraMax
®
L baseplate to the
StakMax bracket.
4. Thread the included Phillips-head screws through the side of the
baseplate and into the threads on the StakMax “L” bracket and
then tighten the screws. See Figure 2-9.
Figure 2-9 Attaching the SpectraMax
®
L baseplate to the
StakMax “L” bracket.
