Installation and Set Up
32 5016072 A
2. Use the 2.5 mm hex key screwdriver to tighten the screws, as
shown in Figure 2-19.
Figure 2-19 Attaching the StakMax microplate handler stand to
the reader
Item Description
1 Front Screw
2 Rear Screw
2
1
