Identifying Status Indicators
English
17
LED Indicator
The LED indicator shows the
operational status of your radio.
Solid red – Radio is
transmitting.
Blinking red – Radio is
transmitting at low battery
condition.
Double blinking red – Radio is
transmitting or receiving an
emergency call.
Solid yellow – Channel is
busy.
Blinking yellow – Radio is receiving a secured transmission.
Solid green – Radio is powering up, or is scanning for activity.
Blinking green – Radio is receiving an individual call, or is
scanning a Priority-Two channel.
Double blinking green – Radio is scanning a Priority-One
channel.
Sent
Stores the messages that you have already
sent. The Sent folder can hold up to 10
messages.
Back
Brings you back to the TMS main menu or
previous menu.
Edit Brings you to the Quick Text Messages screen.
Save Saves your messages to the Draft folder.
Rply Replies to a message.
Del Deletes a message.
Addr
Keys in the target address, or selects one from
the list.
New Composes a new message.
List Selects a predefined message.
Impt
Toggles on or off the “Priority” flag for an
outgoing message.
Rqrp
Toggles on or off the “Request Reply” flag for
an outgoing message.
Curr Deletes the current selected message.
All
Deletes all the messages in the current
message folder.
Menu
Option
Description/Function
LED Indicator
6875945M01-A_Full.book Page 17 Tuesday, July 8, 2008 12:54 AM
