Motorola iDEN Site Controller User Manual

Chapter 6 System Testing Gen 3 Site Controller System Manual
EAS/EAS2 Alarm Checkout
6-28 68P80801E30-A 5/1/2002
Switch off the RFS1 breaker of RFC2 RFC 2 circuit breaker and combiner/
multicoupler power supply
Switch off the RFS1 breaker of RFC3 RFC 3 circuit breaker and combiner/
multicoupler power supply
Switch off both RFS1&2 breakers of
RFC1
RFC 1 combiner/multicoupler
amplifier
RFC 1 combiner/power supply
RFC 1 circuit breaker
RFC 1 tower top amplifier *
Switch off both RFS1&2 breakers of
RFC2
RFC 2 combiner/multicoupler
amplifier
RFC 2 combiner/power supply
RFC 2 circuit breaker
RFC 2 tower top amplifier *
Switch off both RFS1&2 breakers of
RFC3
RFC 3 combiner/multicoupler
amplifier
RFC 3 combiner/power supply
RFC 3 circuit breaker
RFC 3 tower top amplifier *
Switch off the AC circuit breaker for
rectifier 1 at the site power panel
AC power failure
Minor rectifier alarm
Switch off any breaker in the Power
Supply rack **
Power system breaker fail
If possible, turn off the AC power for
rectifiers 1 and 2 in the Power Supply
rack
Major rectifier alarm
Switch off any RF Cabinet 1 breaker RFC 1 circuit breaker
Switch off any RF Cabinet 2 breaker RFC 2 circuit breaker
Switch off any RF Cabinet 3 breaker RFC 3 circuit breaker
* Only present on RF Cabinets containing cavity combining RF Distribution Systems.
** Breaker alarms may take time to appear.
Table 6-4 Alarm action and alarm responses — continued
If you do this . . . Then this alarm triggers . . .
