68P80801E30-A 5/1/2002 4-5
Gen 3 Site Controller System Manual Chapter 4 Installation
Cabinet Installation
Cabinet Position Considerations
Sector Identication
Refer to the EBTS System Manual (in print: 68P81099E10; on CD:
98P80800A03) for details on sector identification.
Cabinet Installation Instructions
The following procedures describe how to mount non-wheeled cabinets in a
system site building. Be sure to read all of the procedures carefully to ensure
a quality installation.
Cabinets must be secured to the floor for optimum stability. Since the
cabinets are very heavy, this procedure is written so that each cabinet is
moved only once.
Motorola recommends installing the first cabinet at the far end of the row,
and then installing adjacent cabinets until the row is completed.
Perform the following steps to properly install the cabinets within the site
building:
1. Measure the mounting location for the first cabinet in the row.
2. Carefully mark the mounting holes with a pencil, as indicated on the
appropriate cabinet footprint.
3. Drill the marked mounting holes to the appropriate depth of the
mounting hardware with a hammer drill and bit.
Refer to the Parts and Suppliers appendix for recommended mounting
hardware.
4. Insert an anchor into the drilled hole.
If necessary, tap the anchor into place using a hammer.
5. Remove the four screws securing the bottom kick panel to the front
and back of the cabinet.
Remove the kick panel and set aside during installation.
