Motorola iDEN Site Controller User Manual

Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-52 68P80801E30-A 5/1/2002
Table 4-24 Punch block 1 (system alarm) pinouts
Alarm
code
EAS/EAS2 function
Punch block 2
signal pairs (left side)
(NOTE)
Punch block 1
signal pairs (right side)
210 reserved for system use 23
48
219 Site entry 7
32
220 Site high ambient temperature 8
33
221 Site low ambient temperature 9
34
223 Site AC surge protector 11
36
224 reserved for system use 22
47
241 RFC #4 circuit breaker 28 21
346
242 AC power failure 12
37
243 LO DC voltage 13
38
244 HI DC voltage 14
39
245 Breaker alarm failure 15
40
246 Minor rectifier module failure 16
41
