68P80801E30-A 5/1/2002 B-3
Gen 3 Site Controller System Manual Appendix B Parts & Suppliers
■ Base Radio antenna (800 MHz cavity combined, transmit only; up to 5
channels) - IS-CT50HN-MA
■ Base Radio antennas (800 MHz duplexed) - IS-CT50HN-MA
■ Base Radio antennas (900 MHz duplexed) - 097-0311G-A.2
■ GPS antennas - 092-082-0T-A
■ lightning arrestor bracket kit - Contact your local Motorola sales
representative to order this kit
■ receive tower top amplifier - 094-0801T-A
■ tower top test port cable - IS-50NX-C2
Polyphaser Corp.
P.O. Box 9000
Minden, NV 89423-9000
Phone: 800-325-7170
702-782-2511
Fax: 702-782-4476
Internet: www.polyphaser.com
Motorola has set up several kits that contain the necessary arrestors with
proper mounting hardware for the various antenna configurations. Contact
your local Motorola representative for these OEM kits.
RF attenuators
Several RF attenuators are needed at a site to ensure proper receive
adjustments. The attenuators are used at the LNA sites to offset the excess
gain from the Tower Top amplifiers, to balance the receive path, and to
attenuate the BMR signal path. Use the following specifications when
choosing vendors:
■ 1 dB increments
■ 0.5 dB accuracy or better
■ female N connector / male N connector
■ Specified frequency range
• 800 MHz systems – requires attenuator specification to include
806-821 MHz range
• 900 MHz systems – requires attenuator specification to include
896-901 MHz range
