Motorola iDEN Site Controller - Table 4-16 Alarm Intercabling

68P80801E30-A 5/1/2002 4-31
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
Table 4-16 Alarm intercabling
System/Site Type Intercabling Connections
Perform Cabling
As Shown In:
800 MHz DUPLEXED RFDS (0182020V06 and earlier)
1-5 Channel Omni • EAS/EAS2 RF#1 to Main RFC ALARM
connector
Figure 4-13
5-8 Channel Duplex Hybrid Expansion • EAS/EAS2 RF#1 to Main RFC ALARM
connector
• EAS/EAS2 RF#2 to Expansion RFC ALARM
connector on Power Supply Tray
Figure 4-13
9-12 Channel Duplex Hybrid
Expansion
• EAS/EAS2 RF#1 to Main RFC ALARM
connector
• EAS/EAS2 RF#2 to Expansion RFC #1 ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#3 to Expansion RF Cabinet #2
ALARM connector on Power Supply Tray
Figure 4-13
Sectored • EAS/EAS2 RF#1 to Main RFC #1 ALARM
connector
• EAS/EAS2 RF#2 to Main RFC #2 ALARM
connector
• EAS/EAS2 RF#3 to Main RFC #3 ALARM
connector
Figure 4-13
800 MHz GEN 4 DUPLEXED RFDS
1-6 Channel Omni • EAS/EAS2 RF#1 to Main RFC alarm connector
on Rx Tray
Figure 4-14
7-12 Channel Omni Expansion • EAS/EAS2 RF#1 to Main RFC alarm connector
on Rx Tray
• EAS/EAS2 RF#2 to Expansion RFC alarm
connector on Rx Tray
Figure 4-14
13-18 Channel Omni Expansion • EAS/EAS2 RF#1 to Main RFC alarm connector
on Rx Tray
• EAS/EAS2 RF#2 to Expansion RFC #1 alarm
connector on Rx Tray
• EAS/EAS2 RF#3 to Expansion RFC #2 alarm
connector on Rx Tray
Figure 4-14
