Chapter 3 Pre-Installation Gen 3 Site Controller System Manual
Site Planning
3-8 68P80801E30-A 5/1/2002
Special Considerations
Breaker Panel Access
The National Electrical Code (NEC) requires a 36” clearance for electrical
service access to all fuse panels, breaker panels, etc., and requires that all
doors to this equipment open to at least 90˚.
10-32 OR 12-24 SCREWS
MAIN BRACKET
(QTY 2)
M4 SCREWS
(QTY 12)
ATTACH GROUND
BRACKET FOR STATIC
STRAP WHERE NEEDED
M6 ZINC PLATED
STEEL SCREWS
(QTY 4)
JUNCTION PANEL
ISC301
050401JNM
ANGLE BRACKET
(QTY 4)
M10 NUT FOR
JUNCTION PANEL
GROUND STUD
(QTY 2)
M6 NUT FOR
JUNCTION PANEL
GROUND STUD
(QTY 3)
M6 BLACK SCREWS
1U BLANK PANEL
(QTY 2)
Figure 3-3 Assembly for mounting in a Power Supply cabinet
