Chapter 6 System Testing Gen 3 Site Controller System Manual
Site Reference
6-32 68P80801E30-A 5/1/2002
.
Figure 6-3 Site Reference - 25% and 75% duty cycle pulse mask
135 nSec
2.0V
0.8V
35
nSec
135 nSec
2.0V
0.8V
35
nSec
iSC092
100296JNM
25% DUTY CYCLE
75% DUTY CYCLE
