68P80801E30-A 5/1/2002 4-3
Gen 3 Site Controller System Manual Chapter 4 Installation
Cabinet Installation
Cabinet Installation
This section provides installation instructions for cabinets already
containing site controllers and provides procedures for permanently
mounting the equipment cabinets within a site. This section contains the
following sections.
Note: This section does not refer to the Power Supply Rack or battery rack.
Refer to the manufacturer’s installation manual for information
relating to these cabinets.
Cabinet Bracing Considerations
Installation for each type of cabinet is slightly different. The cabinets are
self-supporting structures. The cabinets require additional bracing during
shipment of prefabricated sites.
In seismically active areas, additional bracing of the cabinet may be required
to prevent it from tipping. However, the bracing hardware must be locally
procured. There are no specific procedures within this manual for bracing
cabinets in active seismic areas.
Section Page This section . . .
Cabinet Bracing Considerations 4-3 describes considerations for
properly bracing cabinets
Cabling Considerations 4-4 describes considerations for
intercabling between cabinets
Access Considerations 4-4 describes considerations for access
to cabinets during servicing
Cabinet Position Considerations 4-5 describes considerations and
mounting procedures for cabinets
