Site Controller Cabling
C-2 68P80801E30-A 5/1/2002
Site Controller Cabling
Site controller cabling refers to the cable connections between the Circuit
Breaker Panel, Junction Panel, EAS/EAS2, Controller A, and Controller B.
Table C-1 identifies and Figure C-1 and Figure C-2 show standard T1 site
controller cabling.
Table C-1 T1 Site Controller cabling
Index
number
Part
number
From To Notes
1 3083609X01
CTL A EAS connector
on Circuit Breaker
Panel
Bat connector on
Controller A
Y-cable that supplies power to
Controller A and the EAS/EAS2
Battery connector on
EAS/EAS2
2 3082082X02 CTL B connector on
Circuit Breaker Panel
Bat connector on
Controller B
supplies power to Controller B
3 3082004X02 ETHERNET 10B2-1
connector on Junction
Panel
Y-connector tap on
Controller A, 10B2-1
Connector
4 3082004X02 ETHERNET 10B2-2
connector on Junction
Panel
Y-connector tap on
Controller A, 10B2-2
Connector
5 3082004X02 ETHERNET 10B2-3
connector on Junction
Panel
Y-connector tap on
Controller A, 10B2-3
Connector
6 5882669Y01 10B2-1 connector on
Controller A
- BNC Y-connector
7 5882669Y01 10B2-2 connector on
Controller A
- BNC Y-connector
8 5882669Y01 10B2-3 connector on
Controller A
– BNC Y-connector
9 5882669Y01 10B2-1 connector on
Controller B
- BNC Y-connector
10 5882669Y01 10B2-2 connector on
Controller B
- BNC Y-connector
