Motorola iDEN Site Controller User Manual

68P80801E30-A 5/1/2002 C-3
Gen 3 Site Controller System Manual Appendix C Cabling Diagrams
Site Controller Cabling
11 5882669Y01 10B2-3 connector on
Controller B
- BNC Y-connector
12 3013943N19 Y-Connector on
Controller A 10B2-1
connector
Y-Connector on
Controller B 10B2-1
connector
13 3013943N19 Y-Connector on
Controller A 10B2-2
connector
Y-Connector on
Controller B 10B2-2
connector
14 3013943N19 Y-Connector on
Controller A 10B2-3
connector
Y-Connector on
Controller B 10B2-3
connector
15 0909906D01 - Y-Connector on
Controller B 10B2-1
connector
termination for Controller
B 10B2-1
16 0909906D01 - Y-Connector on
Controller B 10B2-2
connector
termination for Controller
B 10B2-2
17 0909906D01 - Y-Connector on
Controller B 10B2-3
connector
termination for Controller
B 10B2-3
18 3082004X02 5 MHz/1 PPS Out 1
connector on Junction
Panel
Y-connector on
Controller A Site Ref
Out - 1 Connector
19 3082004X02 5 MHz/1 PPS Out 2
connector on Junction
Panel
Y-connector on
Controller A Site Ref
Out - 2 Connector
20 3082004X02 5 MHz/1 PPS Out 3
connector on Junction
Panel
Y-connector on
Controller A Site Ref
Out - 3 Connector
21 3013943N05 Y-connector on
Controller A Site Ref
Out - 1 connector
Site Ref Out - 1
Connector on
Controller B
22 3013943N05 Y-connector on
Controller A Site Ref
Out - 2 connector
Site Ref Out - 2
Connector on
Controller B
Table C-1 T1 Site Controller cabling — continued
Index
number
Part
number
From To Notes
