Motorola iDEN Site Controller User Manual

Appendix C Cabling Diagrams Gen 3 Site Controller System Manual
Site Controller Cabling
C-4 68P80801E30-A 5/1/2002
23 3013943N05 Site Ref Out - 3
Y-connector on
Controller A
Site Ref Out - 3
Connector on
Controller B
24 5882669Y01 Site Ref Out-1
connector on
Controller A
- BNC Y-connector
25 5882669Y01 Site Ref Out-2
connector on
Controller A
- BNC Y-connector
26 5882669Y01 Site Ref Out-3
connector on
Controller A
- BNC Y-connector
27 3012028P31 GPS A connector on
Junction Panel
GPS connector on
Controller A
28 3012028P31 GPS B connector on
Junction Panel
GPS connector on
Controller B
29 3083499X01 Controller A -
Parallel connector on
EAS/EAS2
Parallel connector on
Controller A
30 3083499X01 Controller B -
Parallel connector on
EAS/EAS2
Parallel connector on
Controller B
31 5882449V01 - T1/E1 - 1 connector on
Controller A
modular T-adapter
32 5882449V01 - T1/E1 - 2 connector on
Controller A
modular T-adapter
33 3084225N48 modular T-adapter
(5882449V01) on
Controller A T1/E1 - 1
T1/E1 - 1 connector on
Controller B
34 3084225N48 modular T-adapter
(5882449V01) on
Controller A T1/E1 - 2
T1/E1 - 2 connector on
Controller B
35 3084225N24 Redund connector on
Controller A
Redund connector on
Controller B
36 3082070X01 CONTROL connector
on EAS/EAS2
STATUS connector on
Circuit Breaker Panel
37 3082505Y12 10/100B-T connector
on Controller A
10/100B-T connector
on Controller B
Table C-1 T1 Site Controller cabling — continued
Index
number
Part
number
From To Notes
