68P80801E30-A 5/1/2002 10-7
Gen 3 Site Controller System Manual Chapter 10 Environmental Alarm System
EAS Functional Description
Controller B -
Serial
RJ48 Not used
Control RJ48 Alarm connection for the
Equipment Cabinet Circuit Breaker
Panel. The alarm activates when any
breaker trips or is set to the OFF
position.
RF#l modular Alarm connection for Receiver
Multicouplers (RMCs). The alarm
activates if an RMC power supply
or low noise amplifier fails.
RF#2 modular Alarm connection for Receiver
Multicouplers (RMCs). The alarm
activates if an RMC power supply
or low noise amplifier fails.
RF#3 modular Alarm connection for Receiver
Multicouplers (RMCs). The alarm
activates if an RMC power supply
or low noise amplifier fails.
Table 10-3 EAS Connectors
Connector Type Description
