68P80801E30-A 5/1/2002 11-7
Gen 3 Site Controller System Manual Chapter 11 Gen 2 Environmental Alarm System
EAS2 Functional Description
Controller B -
Parallel
36-pin IEEE 1284 Provides a parallel link for alarm
commands and responses to Site
Controller B.
NOTE:
Alarm commands and
responses pass through an IEEE 1284
cable.
Control RJ48 Alarm connection for the
Equipment Cabinet Circuit Breaker
Panel. The alarm activates when any
breaker trips or is set to the OFF
position.
RF#l modular Alarm connection for Receiver
Multicouplers (RMCs). The alarm
activates if an RMC power supply
or low noise amplifier fails.
RF#2 modular Alarm connection for Receiver
Multicouplers (RMCs). The alarm
activates if an RMC power supply
or low noise amplifier fails.
RF#3 modular Alarm connection for Receiver
Multicouplers (RMCs). The alarm
activates if an RMC power supply
or low noise amplifier fails.
Table 11-3 EAS2 Connectors
Connector Type Description
